Product Details
Place of Origin: CHINA
Brand Name: TISCO,BAOSTEEL.Wisco
Certification: ISO,CE,SGS
Model Number: UNS S30300
Payment & Shipping Terms
Minimum Order Quantity: 1Ton
Price: USD1000-USD2500/Ton
Packaging Details: Standard seaworthy export packing or as customer demands
Delivery Time: 7 Days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 8000 Tons per Month
Name: |
Stainless Steel |
Standard: |
JIS, ASTM, DIN, EN, JIS, AISI,GB,etc |
Surface Finish: |
2B/BA/HL/NO.4/8K/Embossed/Gold/Rose Gold/Black Gold |
Technique: |
Cold Rolled,hot Rolled |
Tolerance: |
Standard Tolerance |
Length: |
Customer Request |
Application: |
In Applications That Require Parts To Be Heavily Machined |
Name: |
Stainless Steel |
Standard: |
JIS, ASTM, DIN, EN, JIS, AISI,GB,etc |
Surface Finish: |
2B/BA/HL/NO.4/8K/Embossed/Gold/Rose Gold/Black Gold |
Technique: |
Cold Rolled,hot Rolled |
Tolerance: |
Standard Tolerance |
Length: |
Customer Request |
Application: |
In Applications That Require Parts To Be Heavily Machined |
Product Description
303 Stainless Steel Plate, Round Bar Non-Magnetic, Austenitic Stainless Steel
Alloy 303 is a non-magnetic, austenitic stainless steel that is not hardenable by heat treatment. It is the free machining modification of the basic 18% chromium / 8% nickel stainless steel. Alloy 303 was specially designed to exhibit improved machinability while maintaining good mechanical and corrosion resistant properties Due to the presence of sulfur in the steel composition, Alloy 303 is the most readily machineable austenitic stainless steel; however, the sulfur addition does lower Alloy 303’s corrosion resistance to below that of Alloy 304. Like other austenitic grades, Alloy 303 demonstrates excellent toughness, although the sulfur does reduce this a little as well.
Specifications Sheet
Chemical Properties:
| % | Cr | Ni | C | Si | Mn | P | S | Mo | Fe |
|---|---|---|---|---|---|---|---|---|---|
| 303 | min: 17.0 max:19.0 |
min: 8.0 max: 10.0 |
0.15 max |
1.00 max |
2.0 max |
0.20 max |
0.15 min | 0.75 | balance |
Mechanical Properties:
| Grade | Tensile Strength ksi (min.) |
Yield Strength 0.2% Offset ksi (min.) |
Elongation - % in 50 mm (min.) |
Hardness (Brinell) MAX |
Hardness (Rockwell B) MAX |
|---|---|---|---|---|---|
| 303 | 75 | 30 | 35 | 228 |
Physical Properties:
| Denstiy lbm/in3 |
Coefficient of Thermal Expansion (min/in)-°F |
Electrical Resistivity mW-in | Thermal Conductivity BTU/hr-ft-°F | Melting Range |
|||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| at 68 °F | at 68 – 212°F | at 68 – 932°F | at 68 – 1450°F | at 68°F | at 212°F | at 392°F | at 752°F | at 1112°F | at 1472°F | at 68 – 212°F | |
| 0.29 | 9.2 | 10.4 | 10.9 | 28.3 | 30.7 | 33.8 | 39.4 | 43.7 | 47.6 | 113.2 | 2552°F |
Product Photo
Packing Photo
Delivery Photo
